MAIN TECHNICAL SPECIFICATION

• Mode: A1-D
• Air Volume: 1000 – 21,000 cfm cfm
• Maximum SP: 3″ wg. @ standard air density

FEATURES & BENEFITS

• G90 galvanized construction
• Easy access doors
• Lifting points
• Pre-wired, pre-piped controls
• Horizontal or down discharge
• Vibration isolation
• High efficiency motors
• Adjustable drive sheaves
• Fully insulated casing
• Stainless steel burner
• 120 volt control transformer with single point electrical connection
• Redundant gas valves
• Intermittent spark pilot with timed safety lockout
• Electronic flame modulation
• High temperature limit switch
• Airflow proving switch
• Economizer inlet thermostat
• Motor starter
• Disconnect switch
• Burner observation port

Options

• Electrical Cabinet LED Lights
• Propane Fuel Application
• Room Override Thermostat
• Motorized Intake Damper
• Remote control panel including summer/winter switch and operating lights
• Freeze Stat with Bypass Timer
• Hi/Low Gas Pressure Switches
• Room Modulating Thermostat
• High Gas Pressure Regulator
• Convenience Outlet
• DX Cooling Coils
• Evaporative Cooler Intake
• V-Bank Filter Intake
• Sloped Filter Intake
• Auxiliary Starters
• Inlet Gas Pressure Gauge
• Indoor Hanging Cradle
• VAV Packages
• Roof Curbs
• Clogged Filter Switch
• Cooling Thermostat and Interlock
• Extra Set of V-Belts
• DDC Control capability for BACnet MS/TP, LonWorks, Johnson N2, and Modbus Protocol
• Z83.18 Recirculating Configuration
